ITPOD-
SL401-D36RE-G4
| Server model | ITPOD-SL401-D36RE-G4 |
| Form factor | 4U |
| Processor | 2 x Intel Xeon Scalable 4th/5th Gen. (TDP up to 350W) |
| RAM | 32 slots of DDR5 RDIMM 4400/4800/5600MHz memory |
| Storage Subsystem | 24 front-facing 2.5" and 3.5" SATA/SAS hot-swappable universal slots 12 hot-swappable 3.5" SATA/SAS slots on the rear side 2 M.2 SATA slots (22110/2280) |
| Expansion Slots | 2 OCP 3.0 slots (PCIe x8) Riser 1: full-height PCIe 5.0 slots (x16 and 2 - x8 or 2 - x16) Riser 2: full-height PCIe 5.0 slots (x16 and 2 - x8 or 2 - x16) Riser 3: half-height PCIe 5.0 slots (1 x16 or 2 x8) or 2.5" Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half-height PCIe 5.0 slots (1 x16 or 2 x8) or 2.5" Rear Module (2 SATA/NVMe U.2 drives) |
| Cooling | 8 standard 80mm x 38mm or 80mm x 56mm hot-swappable fans |
| Power Supplies | 2 pcs (800W/1300W/1600W/2200W/2600W) 1+1 redundancy schemes |
