Hardware and software complexes
Tested and validated by vendors.
A set of systems with unified support for different tasks
A set of systems with unified support for different tasks
vStack HCI is a hyperconverged platform that unifies compute, storage and networking resources
Equipment packages for a quick start
«Start» Pack
6 servers
vStack-R-SL201–D25RE-G3
redundancy = 2
Server Characteristics
- 2 x Intel Xeon Gold 6326 (16C @ 2.9GHz)
- 16 x 64GB RDIMM 3200MHz
- LSI 9400-16i HBA
- 2 x 512GB M.2 NVMe (OS)
- 12 x 960GB SSD SAS (DATA)
- 4 x 10Gb Eth SFP+
Useful cluster resources
- Cluster Usable Space (TB) = 36 TB
- Cluster Effective Space (TB) = 108 TB
- Cluster Usable Cores = 192
- Cluster Usable GHz = 557
- Cluster Effective GHz = 5,011
- Cluster Usable RAM (for VMs) = 3,328 GB
«Optimal» Pack
12 servers
vStack-R-SL201–D25RE-G3
redundancy = 2
Server Characteristics
- 2 x Intel Xeon Gold 6348 (28C @ 2.6GHz)
- 32 x 64GB RDIMM 3200MHz
- LSI 9400-16i HBA
- 2 x 512GB M.2 NVMe (OS)
- 24 x 960GB SSD SAS (DATA)
- 4 x 25Gb Eth SFP28
Useful cluster resources
- Cluster Usable Space (TB) = 180 TB
- Cluster Effective Space (TB) = 540 TB
- Cluster Usable Cores = 672
- Cluster Usable GHz = 1,706
- Cluster Effective GHz = 15,356
- Cluster Usable RAM (for VMs) = 11,136 GB
Not suitable for these configurations? Describe your tasks and we will contact you as soon as possible.
Stingray Service Gateway variants depending on performance
| Platform | SSG 20 | SSG 40 | SSG 100 |
|---|---|---|---|
| Performance Gbit | up to 20 | up to 40 | up to 100 |
| Ports | 4 x 10Gb SFP+ 2 × 40Gb QSFP+ | 6 × 10Gb SFP+ 4 × 40Gb QSFP+ | 20 × 10Gb SFP+, 8 × 25Gb SFP28, 8 × 40Gb QSFP+, 2 x 100Gb QSFP28 |
| Number of Subscribers Mln | 2 | 4 | 16 |
| Maximum number of sessions Mln | 16 | 32 | 128 |
| Number of new sessions Mln | 0.5 | 1 | 2.5 |
| Average latency (ms) | 30 | 30 | 30 |
